Underground Utility Experts
Specializing in Culvert Cleaning, Culvert Restoration, and Subsurface Drainage
Specializing in Culvert Cleaning, Culvert Restoration, and Subsurface Drainage
A head-to-head study was performed with HURK’s process and a jetter truck. The study was performed on a culvert consisting of 2 identical pipes with the same amount of silt inside each pipe. The first pipe was cleaned with a jet truck and was completed in 6.5 hours and used 1200 gallons of water. The second pipe was cleaned using HURK’s process, which was done in 40 minutes and used 110 gallons of water.
When using a jetter truck, potentially thousands of gallons of water can be used to clean a culvert effectively. HURK’s method will use a fraction of that. For example, a 60′ culvert with a diameter of 24″ that is 100% full can be cleaned using between 100-250 gallons of water. Using HURK’s method, the water usage and pressure are controlled by the drill operator. The water is pumped through the drill stem to the culvert cleaning attachments.
Using a directional drill gives the operator complete control of the debris within a culvert. With controlled pullback and thrust speeds, the operator can remove as little or as much material as they want at a controlled speed. This will allow for the material to be shoveled, excavated, or vacuumed as it is being removed from the culvert. Using a pull bucket or push bucket, the material can be removed from either end of a culvert.
The culvert cleaning tools are built out of mild steel that will not damage the interior of the culvert. Using a directional drill allows the operator to control the rotation of the tools. This is very important, especially when a failure or void is encountered. With total control, the operator will be able to back out the tool to determine where the failure is.
HURK Underground Technologies is a company that specializes in culvert cleaning, culvert restoration, and specialized subsurface drainage. Through patented technologies and methodologies, HURK Underground Technologies can effectively and efficiently clean and restore clogged and damaged culverts.
The revolutionary process involves using a patented method utilizing a directional drill and patented attachments to clean culverts. HURK Underground Technologies has the ability to clean round, arch, and box structures and restore flow to 100%. This process has the ability to clean pipes that are 100% clogged and obstructed by soil, rocks, roots, or any type of material.
HURK Underground Technologies has the ability to clean round, arch, and box structures and restore flow to 100%.
The use of a directional drill offers many advantages, including tool rotation, control of water injection and pressure, and the ability to span any length of culvert pipe with additional drill rods. The patented attachments give us great flexibility in our cleaning process. The attachments include barrel reamers, push buckets, pull buckets, and brushes.
